WHITE Cat6 Jack To Suit Clipsal Plate

Stock Code:
RJO1631-WH
Price:
$4.00 excl GST

Description

MATERIAL:
Keystone Jack Housing: PC + ABS polymer high-impact UL94V-0 thermoplastic
Contact Holder: PC + ABS polymer high-impact UL94V-0 thermoplastic
Spring Wire: Phosphor bronze 5100w temper wire Dia= 0.45mm
3U" AU/30U" PDNI over 60U" Nickle undercoat
IDC Plastic: Polycarbonate resin high-impact UL94V-0 Thermoplastic
IDC Contact: Phosphor bronze C5191R-H, T=0.4mm, 200U" Tin over 60U" Nickle undercoat

PHYSICAL CHARACTERISTICS:
Intertion Life: 750 mating cycles with FCC compliant RJ-45 plug
Contact Force: 100 grams with FCC compliant RJ-45 plug
Plug Retention Force: 11LBF Min
Durability: 200 Termination cycles
Contact Compability Accommodate 22 to 26 AWG Solid/ 24 AWG Stranded
Operating Temperature Range: -10Dc To 60Dc
Storage Temperature Range: -40Dc To 68Dc
Humidity: 10% ~ 90%RH

ELECTRICAL:
Insulation Resistance: 500Mohm
Dielectric Withstanding Voltage: 1000V
DC Resistance: 0.1Ohm
Contact Resistance: 20Mohm
